ВАLTECH GmbH - State-of-art vibration diagnostics, balancing, vibration check and vibration monitoring |
Periodic vibration monitoring (monthly) and balancing in own bearings are easily performed with the new vibrometer-balancer BALTECH VP-3470. Vibration diagnostics and check are helpful for detecting features of rotor unbalance or misalignment based on vibration spectrum.
Steps of balancing with the vibration analyzer BALTECH VP-3470.
1. Vibration level measurement.
2. Test weight installation
3. Vibration level measurement after the test weight installation
4. Calculation of balancing mass value and angle
5. Addition or removing of the balancing mass
6. Check measurement
7. Report creation
Dynamic balancing is conducted on 4 planes and 16 vibration measurement points. BALTECH VP-3470 lets conduct vibration analysis of harmonics of rotation frequency for determination of vibration cause. Balancing reports can be saved in the device and transferred into the software BALTECH Expert.
functional capacities of BALTECH VP-3470:
2-channel measurement and vibration analysis (2 vibration channels, 1 tach channel)
• Vibration meter mode: vibration overall level measurement (velocity, acceleration, displacement, RMS, Peak, excess). Permanent vibration check and monitoring.
• Phase meter mode
• Tachometer mode
• Vector calculator
• Multi plane balancing (4 planes, 16 measurement points, test run, dynamic influence coefficient)
• Test weight calculation
• Balancing mass and angle calculation
• Stroboscope connection for determination of precise rotation speed.
• Waveform measurement (oscilloscope)
• Spectral analysis (velocity, acceleration, displacement)
• Waveform and spectral analysis of envelope
• The measured data can be transferred from BALTECH VP-3470 to the BALTECH Expert software for data analysis, trending, diagnostics and reporting.
• Computer control with extended analysis opportunities
